Foundry An casting capabilities in Konya, Turkey
What does Foundry An in Konya, Turkey produce?
Foundry An supplies cast iron, ductile iron, and steel castings made in its own foundry and aluminium castings sourced from partner foundries.
Which material families are available?
We cast grey cast iron (EN‑GJL) and ductile iron (EN‑GJS) in‑house; steel castings are also produced on site, while aluminium parts are procured through vetted partners.
What casting processes are used?
Green sand moulding, resin sand moulding, and CNC machining are performed in‑house; pattern making and batch‑wise chemical, mechanical and non‑destructive testing are also provided.
How are quality and compliance ensured?
Our sales are covered by ISO 9001:2015 (certificate MTS‑51752, issued 23‑07‑2026, valid to 22‑07‑2027) and we follow EN 1561 for grey iron, EN 1563 for ductile iron, EN 10293 for steel castings, ISO 8062 for dimensional tolerances, and ISO 945 for graphite classification.
What are the standard material designations?
| Material family | Standard designation | Typical applications |
|---|---|---|
| Grey cast iron | EN‑GJL | engine blocks, pump housings |
| Ductile iron | EN‑GJS | gear wheels, hydraulic cylinders |
| Cast steel | EN‑10293 | high‑load shafts, turbine blades |
| Aluminium (partner sourced) | EN‑573‑3 (typical alloy families) | lightweight brackets, heat exchangers |
When should I choose in‑house casting versus a partner source?
Use in‑house casting for EN‑GJL, EN‑GJS, and steel when you need direct control of the full production chain; select partner‑sourced aluminium when weight reduction is critical and you accept an external supplier.
What are the exceptions to the general material selection?
If a part requires a specific alloy grade not covered by EN‑GJL or EN‑GJS, we discuss alternatives with you; for ultra‑high‑strength steel beyond EN‑10293 limits, external specialist foundries may be engaged.
FAQ
Can I send a 3D CAD model instead of 2D drawings?
Yes, we accept STEP or IGES files for CNC machining and mould design.
Do you perform heat treatment on steel castings?
Heat treatment is offered through our partner network; we coordinate the process and provide certification.
What is the typical lead time for a 5 tonne production batch?
Lead time depends on material, quantity, and tooling; please contact us with the drawing for a precise schedule.
Send your drawing to contact@foundry-an.com to start the quotation.
